Aquaculture Fish Farm Waterproof Geomembrane HDPE Geomembrane Liner – Waterproof Barrier for Dam, Fish Farm, Pond, Pool, Tank

Aquaculture Fish Farm Waterproof Geomembrane Pond Liner HDPE High Density for Landfill Dam Soil Protection

HDPE Geomembrane Pond Liner is a high-performance, low-permeability synthetic liner, manufactured in full compliance with GRI GM13 standards. It is produced using 100% virgin polyethylene resin—formulated with carbon black, antioxidants, UV stabilizers, and anti-aging additives—to ensure long-term durability and resistance to environmental stress.

This geomembrane liner features a smooth surface, designed specifically for exposed applications that require superior UV resistance, chemical stability, and impermeability. It serves as a robust containment solution for a wide range of geotechnical and environmental engineering projects.

HDPE Geomembrane Application:
(1)Aquaculture:
Using the geomembrane anti-seepage feature; geomembrane liners can be used as fish ponds, shrimp pond, tank liner and others.
(2)Landfill:
HDPE geomembrane is the most widely used in landfill anti-seepage engineering material. The use of main parts of the bottom of the landfill liner, landfill sealing cover, leachate regulating pool liner, etc.
(3)Water Treatment System :
HDPE geomembrane is applied to the adjustment of the power plant and sewage treatment plants pool;and a series of water treatment systems.
(4)Mining:
HDPE geomembrane suitable mining: washing pool, pool heap leaching, heap yard, dissolving tank, tank, storage area, the bottom line of the tailings seepage control, etc

Geomembrane Pond Liner Technical Parameter

ASTM Standard geomembrane pond liner

Characteristics:

1. Superior flexibility

2. Extreme temperature tolerance (-70°C to 110°C)

3. Chemical corrosion & aging resistance

4. Exceptional environmental stress cracking (ESC) resistance

5. High tensile strength with elongation capacity

6.

Main Features:

1. UV-resistant

2. Impermeable barrier

3. Reliable isolation

4. High tear-resistant

5. Puncture-proof

HDPE Geomembrane Application:
(1) Aquaculture:
Utilizing the geomembrane pond liner's anti-seepage properties, our geomembrane pond liner serves as:

• Fish farm

• Shrimp containment

• Tank sealing

• Recirculating aquaculture

(2) Landfill:
As the industry-standard geomembrane pond liner solution:

• Base geomembrane pond liner for landfill bottoms

• Capping geomembrane pond liner closure systems

• Leachate collection geomembrane pond liner

• Regulation pond geomembrane pond liner

(3) Water Treatment Systems:
Critical geomembrane pond liner applications include:

• Power plant cooling geomembrane pond liner

• Wastewater treatment geomembrane pond liner

• Equalization basin geomembrane pond liner

• Potable water geomembrane pond liner reservoirs

(4) Mining:
Heavy-duty geomembrane pond liner installations:

• Heap leach pad

• Tailings storage

• Process solution

• Sediment control

• Acid rock drainage containment

  Product Specification



  HDPE Geomembrane pond liner Technical Parameter

  ASTM Standard geomembrane

  Spec Properties	Test method ASTM	GMS0.5	GMS0.75	GMS1.0	GMS1.25	GMS1.5	GMS2.0	GMS2.5
  Thickness	D5199	0.5mm	0.75mm	1.00mm	1.25mm	1.50mm	2.00mm	2.50mm
  Density (≥ g/cc)	D1505	0.940	0.940	0.940	0.940	0.940	0.940	0.940
  Tensile Properties (Each direction) (≥) • yield strength • break strength • yield elongation • break elongation	D 6693 Type IV	8 kN/m 14kN/m 12% 700%	11 kN/m 20kN/m 12% 700%	15 kN/m 27 kN/m 12% 700%	18 kN/m 33 kN/m 12% 700%	22 kN/m 40 kN/m 12% 700%	29 kN/m 53 kN/m 12% 700%	37kN/m 67kN/m 12% 700%
  Tear Resistance (≥)	D 1004	64 N	93 N	125 N	156 N	187 N	249 N	311 N
  Puncture Resistance (≥)	D 4833	160 N	240 N	320 N	400 N	480 N	640 N	800 N
  Stress Crack Resistance (≥)	D 5397	500 hr.	500 hr.	500 hr.	500 hr.	500 hr.	500 hr.	500 hr.
  Carbon Black Content	D 1603	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%	2.0-3.0%
  Carbon Black Dispersion	D 5596	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)	Note(1)
  Oxidative Induction Time (OIT) (≥) (a)Standard OIT - or - (b)High Pressure OIT	D 3895 D 5885	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.	100 min. 400 min.
